Token based authentication with Silex and AngularJS

According to my last post today we’re going to create a AngularJS application that uses the Silex Backend that we create previously. The idea of this application is to use it within a Phonegap/Cordova application running in a mobile device.

The application will be show a login form if device haven’t a correct token.

Gonzalo_Login_Example_and_LoginServiceProvider_php_-_token_-____work_projects_token_

And whit a correct token:

Gonzalo_Login_Example

Nothing new under the sun, isn’t it?

Our front-end application will use AngularJS and Topcoat.

<!DOCTYPE html>
<html xmlns:ng="http://angularjs.org" lang="es" ng-app="G">
<head>
    <meta charset="utf-8"/>
    <meta name="format-detection" content="telephone=no"/>
    <!-- WARNING: for iOS 7, remove the width=device-width and height=device-height attributes. See https://issues.apache.org/jira/browse/CB-4323 -->
    <meta name="viewport"
          content="user-scalable=no, initial-scale=1, maximum-scale=1, minimum-scale=1, width=device-width, height=device-height, target-densitydpi=device-dpi"/>
    <link rel="stylesheet" type="text/css" href="/bower_components/topcoat/css/topcoat-mobile-light.min.css">
    <title>Gonzalo Login Example</title>
</head>
<body ng-controller="MainController">

<div ng-view class="main-content"></div>

<script src="/bower_components/angular/angular.min.js"></script>
<script src="/bower_components/angular-route/angular-route.min.js"></script>

<script src="js/app.js"></script>
<script src="js/services.js"></script>

</body>
</html>

And our AngularJS application:

'use strict';
var appControllers, G;
var host = 'http://localhost:8080'; // server API url

appControllers = angular.module('appControllers', []);
G = angular.module('G', ['ngRoute', 'appControllers']);

G.run(function (httpG) {
    httpG.setHost(host);
});

G.config(['$routeProvider', function ($routeProvider) {
    $routeProvider.
        when('/login', {templateUrl: 'partials/login.html', controller: 'LoginController'}).
        when('/home', {templateUrl: 'partials/home.html', controller: 'HomeController'});
}]);

appControllers.controller('HomeController', ['$scope', 'httpG', '$location', function ($scope, httpG, $location) {
    $scope.hello = function () {
        httpG.get('/api/info').success(function (data) {
            if (data.status) {
                alert("Hello " + data.info.name + " " + data.info.surname);
            }
        });
    };

    $scope.logOut = function () {
        alert("Good bye!");
        httpG.removeToken();
        $scope.isAuthenticated = false;
        $location.path('login');
    };
}]);

appControllers.controller('MainController', ['$scope', '$location', 'httpG', function ($scope, $location, httpG) {
    $scope.isAuthenticated = false;

    if (httpG.getToken()) {
        $scope.isAuthenticated = true;
        $location.path('home');
    } else {
        $location.path('login');
    }
}]);


appControllers.controller('LoginController', ['$scope', '$location', 'httpG', function ($scope, $location, httpG) {
    $scope.user = {};

    $scope.doLogIn = function () {
        httpG.get('/auth/validateCredentials', {user: $scope.user.username, pass: $scope.user.password}).success(function (data) {
            if (data.status) {
                httpG.setToken(data.info.token);
                $scope.isAuthenticated = true;
                $location.path('home');
            } else {
                alert("login error");
            }
        }).error(function (error) {
            alert("Login Error!");
        });
    };

    $scope.doLogOut = function () {
        httpG.removeToken();
    };
}]);

In this example I’m using angular-route to handle the application’s routes. Nowadays I’m swaping to angular-ui-router, but this example I’m still using “old-style” routes. We define two partials:

partial/home.html

<div class="topcoat-button-bar full" style="position: fixed; bottom: 0px;">
    <label class="topcoat-button-bar__item">
        <button class="topcoat-button full" ng-click="logOut()">
            <span class="">Logout</span>
        </button>
    </label>
    <label class="topcoat-button-bar__item">
        <button class="topcoat-button--cta full" ng-click="hello()">
            <span class="">Hello</span>
        </button>
    </label>
</div>

partial/login.html

<div class="topcoat-navigation-bar">
    <div class="topcoat-navigation-bar__item center full">
        <h1 class="topcoat-navigation-bar__title">Login</h1>
    </div>
</div>

<ul class="topcoat-list__container">
    <li class="topcoat-list__item center">
        <input ng-model="user.username" class="topcoat-text-input--large" type="text" name="user"
               placeholder="Username"/>
    </li>
    <li class="topcoat-list__item center">
        <input ng-model="user.password" class="topcoat-text-input--large" type="password" name="pass"
               placeholder="Password"/>
    </li>
</ul>

<div class="topcoat-button-bar full" style="position: fixed; bottom: 0px;">
    <label class="topcoat-button-bar__item">
        <button class="topcoat-button--cta full" ng-click="doLogIn()">
            <span class="">Login</span>
        </button>
    </label>
</div>

As we can see in the application we’re using a service to handle Http connections with the token information.

'use strict';

G.factory('httpG', ['$http', '$window', function ($http, $window) {
    var serviceToken, serviceHost, tokenKey;
    tokenKey = 'token';
    if (localStorage.getItem(tokenKey)) {
        serviceToken = $window.localStorage.getItem(tokenKey);
    }

    $http.defaults.headers.post["Content-Type"] = "application/x-www-form-urlencoded";

    return {
        setHost: function (host) {
            serviceHost = host;
        },

        setToken: function (token) {
            serviceToken = token;
            $window.localStorage.setItem(tokenKey, token);
        },

        getToken: function () {
            return serviceToken;
        },

        removeToken: function() {
            serviceToken = undefined;
            $window.localStorage.removeItem(tokenKey);
        },

        get: function (uri, params) {
            params = params || {};
            params['_token'] = serviceToken;
            return $http.get(serviceHost + uri, {params: params});
        },

        post: function (uri, params) {
            params = params || {};
            params['_token'] = serviceToken;

            return $http.post(serviceHost + uri, params);
        }
    };
}]);

And that’s all. You can see the full example in my github account.

Token based authentication with Silex Applications

Imagine this simple Silex application:

use Silex\Application;

$app = new Application();

$app->get('/api/info', function (Application $app) {
    return $app->json([
        'status' => true,
        'info'   => [
            'name'    => 'Gonzalo',
            'surname' => 'Ayuso'
        ]]);
});

$app->run();

What happens if we want to use a security layer? We can use sessions. Sessions are the “standard” way to perform authentication in web applications, but when our application is a PhoneGap/Cordova application that uses a Silex server as API server, sessions aren’t the best way. The best way now is a token based authentication. The idea is simple. First we need a valid token. Our API server will give us a valid token if we send valid credentials in a login form. Then we need to send the token with each request (the same way than we send the session cookie with each request).

With Silex we can check this token and validate.

use Silex\Application;

$app = new Application();

$app->get('/api/info', function (Application $app) {
    $token = $app->get('_token');

    // here we need to validate the token ...

    return $app->json([
        'status' => true,
        'info'   => [
            'name'    => 'Gonzalo',
            'surname' => 'Ayuso'
        ]]);
});

$app->run();

It isn’t an elegant solution. We need to validate the token within all routes and that’s bored. We also can use middlewares and validates the token with $app->before(). We’re going to build something like this, but with a few variations. First I want to keep the main application as clean as possible. Validation logic must be separated from application logic, so we will extend Silex\Application. Our main application will be like this:

use G\Silex\Application;

$app = new Application();

$app->get('/api/info', function (Application $app) {
    return $app->json([
        'status' => true,
        'info'   => [
            'name'    => 'Gonzalo',
            'surname' => 'Ayuso'
        ]]);
});

$app->run();

Instead of Silex\Application we’ll use G\Silex\Application.

namespace G\Silex;

use Silex\Application as SilexApplication;
use G\Silex\Provider\Login\LoginBuilder;
use Symfony\Component\HttpFoundation\Request;
use Symfony\Component\HttpFoundation\Response;

class Application extends SilexApplication
{
    public function __construct(array $values = [])
    {
        parent::__construct($values);

        LoginBuilder::mountProviderIntoApplication('/auth', $this);

        $this->after(function (Request $request, Response $response) {
            $response->headers->set('Access-Control-Allow-Origin', '*');
        });
    }
}

Our new G\Silex\Application is a Silex\Application enabling CORS. We also mount a Service provider.

The responsibility of our API server will be check the token of every request and to provide one way to get a new token. To get a new token we will create a route “/auth/validateCredentials”. If a valid credentials are given, new token will be send to client.

Our Service provider has two parts: a service provider and a controller provider.

To mount both providers we will use a LoginBuilder class:

namespace G\Silex\Provider\Login;

use Silex\Application;

class LoginBuilder
{
    public static function mountProviderIntoApplication($route, Application $app)
    {
        $app->register(new LoginServiceProvider());
        $app->mount($route, (new LoginControllerProvider())->setBaseRoute($route));
    }
}

Our Controller provider:

namespace G\Silex\Provider\Login;

use Symfony\Component\HttpKernel\Exception\AccessDeniedHttpException;
use Symfony\Component\HttpFoundation\Request;
use Silex\ControllerProviderInterface;
use Silex\Application;

class LoginControllerProvider implements ControllerProviderInterface
{
    const VALIDATE_CREDENTIALS = '/validateCredentials';
    const TOKEN_HEADER_KEY     = 'X-Token';
    const TOKEN_REQUEST_KEY    = '_token';

    private $baseRoute;

    public function setBaseRoute($baseRoute)
    {
        $this->baseRoute = $baseRoute;

        return $this;
    }

    public function connect(Application $app)
    {
        $this->setUpMiddlewares($app);

        return $this->extractControllers($app);
    }

    private function extractControllers(Application $app)
    {
        $controllers = $app['controllers_factory'];

        $controllers->get(self::VALIDATE_CREDENTIALS, function (Request $request) use ($app) {
            $user   = $request->get('user');
            $pass   = $request->get('pass');
            $status = $app[LoginServiceProvider::AUTH_VALIDATE_CREDENTIALS]($user, $pass);

            return $app->json([
                'status' => $status,
                'info'   => $status ? ['token' => $app[LoginServiceProvider::AUTH_NEW_TOKEN]($user)] : []
            ]);
        });

        return $controllers;
    }

    private function setUpMiddlewares(Application $app)
    {
        $app->before(function (Request $request) use ($app) {
            if (!$this->isAuthRequiredForPath($request->getPathInfo())) {
                if (!$this->isValidTokenForApplication($app, $this->getTokenFromRequest($request))) {
                    throw new AccessDeniedHttpException('Access Denied');
                }
            }
        });
    }

    private function getTokenFromRequest(Request $request)
    {
        return $request->headers->get(self::TOKEN_HEADER_KEY, $request->get(self::TOKEN_REQUEST_KEY));
    }

    private function isAuthRequiredForPath($path)
    {
        return in_array($path, [$this->baseRoute . self::VALIDATE_CREDENTIALS]);
    }

    private function isValidTokenForApplication(Application $app, $token)
    {
        return $app[LoginServiceProvider::AUTH_VALIDATE_TOKEN]($token);
    }
}

And our Service provider:

namespace G\Silex\Provider\Login;

use Silex\Application;
use Silex\ServiceProviderInterface;

class LoginServiceProvider implements ServiceProviderInterface
{
    const AUTH_VALIDATE_CREDENTIALS = 'auth.validate.credentials';
    const AUTH_VALIDATE_TOKEN       = 'auth.validate.token';
    const AUTH_NEW_TOKEN            = 'auth.new.token';

    public function register(Application $app)
    {
        $app[self::AUTH_VALIDATE_CREDENTIALS] = $app->protect(function ($user, $pass) {
            return $this->validateCredentials($user, $pass);
        });

        $app[self::AUTH_VALIDATE_TOKEN] = $app->protect(function ($token) {
            return $this->validateToken($token);
        });

        $app[self::AUTH_NEW_TOKEN] = $app->protect(function ($user) {
            return $this->getNewTokenForUser($user);
        });
    }

    public function boot(Application $app)
    {
    }

    private function validateCredentials($user, $pass)
    {
        return $user == $pass;
    }

    private function validateToken($token)
    {
        return $token == 'a';
    }

    private function getNewTokenForUser($user)
    {
        return 'a';
    }
}

Our Service provider will have the logic to validate credentials, token and it must be able to generate a new token:

    private function validateCredentials($user, $pass)
    {
        return $user == $pass;
    }

    private function validateToken($token)
    {
        return $token == 'a';
    }

    private function getNewTokenForUser($user)
    {
        return 'a';
    }

As we can see the logic of the example is very simple. It’s just an example and here we must to perform our logic. Probably we need to check credentials with our database, and our token must be stored somewhere to be validated later.

You can see the example in my github account. In another post we will see how to build a client application with angularJs to use this API server.

Integrating WebSockets with PHP applications. Silex and socket.io playing together.

WebSockets are great. We can start a persistent connection from our browser to our server and use this connection to send real time notifications to our users. Normally when we integrate WebSockets with an existing Web application, we need to face with one slight problem. Our Web application runs on a Web server (imagine, for example one Silex application). We can use a login form and ensure all requests are authorized (using a security layer). This problem is solved years ago. We can use Basic HTTP authentification, Digtest authentification, a session based authentication, token based authentificatio, OAuth, … The problem arrives when we add WebSocket server. WebSocket server is another serve. We can use node.js, ruby, or even PHP with Rachet. But how we can ensure that WebSocket server’s requests are also authenticated? We can try to share our authentification provider between both servers, but this solution is quite “exotic”. That was the idea behind my blog post: post some time ago. I’ve been thinkin a lot about it, and also read posts and speak with colleages about this subject. Finally I’m using the following solution. Let me explain it.

Websockets are bi-directional. We can get messages in the browser and send them from browser to server. Basically the solution is to disable the messages from the browser to the server via WebSockets. In fact HTML5 provides another tool to do that called Server Side Events (aka SSE), but SSE aren’t as widely used as WebSockets. Because of that I preffer to use WebSockets (without using the browser-to-server chanel) instead of SSE.

Let’s create a simple Silex application:

class Application extends Silex\Application
{
    use Silex\Application\TwigTrait;
}

$app = new Application();

$app->register(new Silex\Provider\TwigServiceProvider(), array(
    'twig.path' => __DIR__ . '/../views',
));

$app->get('/', function () use ($app) {
    return $app->render('home.twig');
});

$app->run();

And our main template with html file

<!DOCTYPE html>
<html>
<head>
    <title></title>
</head>
<body>
<script src="//localhost:8080/socket.io/socket.io.js"></script>
<script>
    var socket = io.connect('//localhost:8080');

    socket.on('id1', function (data) {
        console.log("mensage from websocket: " + data);
    });
</script>
</body>
</html>

Now we have Silex application that connects to a WebSockets server. I will use socket.io to build the WebSocket server:

var CONF = {
        IO: {HOST: '0.0.0.0', PORT: 8080}
    },
    io = require('socket.io').listen(CONF.IO.PORT, CONF.IO.HOST);

Whit this ultra minimal configuration we can connect from Silex application to WebSocket server and our web application will listen to messages marked as’id1′ from the WebSocket server but, how can we do to send messages? As I said before we only rely on Silex application (in this example there isn’t any security layer, but we can use our custom login). The trick is to create a new server within our node.js server. Start this server at localhost and perform a curl request from our Silex Application to our node.js server to send the WebSockets push notifications. The idea is:

  • User clicks a link in our html (generated by our Silex application)
  • This request is a standard Silex request (using our security layer)
  • Then Silex performs a curl request to node.js server.
  • If our Silex application and node.js application are in the same server we will create a new server at localhost. In this example we are going to use Express to do that.
  • Express server will handle requests from our Silex application (not from any other host) and will send WebSocket messages

Now our node.js application will change to

var CONF = {
        IO: {HOST: '0.0.0.0', PORT: 8080},
        EXPRESS: {HOST: 'localhost', PORT: 26300}
    },
    io = require('socket.io').listen(CONF.IO.PORT, CONF.IO.HOST),
    app = require('express')();

app.get('/emit/:id/:message', function (req, res) {
    io.sockets.emit(req.params.id, req.params.message);
    res.json('OK');
});

app.listen(CONF.EXPRESS.PORT, CONF.EXPRESS.HOST);

And our html template will change to (I will use Zepto to perform AJAX requests):

<!DOCTYPE html>
<html>
<head>
    <title></title>
</head>
<body>
<ul>
    <li><a href="#" onclick="emit('id1', 'hello')">emit('id1', 'hello')</a></li>
    <li><a href="#" onclick="emit('id1', 'bye')">emit('id1', 'bye')</a></li>
</ul>
<script src="//localhost:8080/socket.io/socket.io.js"></script>
<script src="//cdnjs.cloudflare.com/ajax/libs/zepto/1.1.1/zepto.min.js"></script>
<script>
    var socket = io.connect('//localhost:8080');

    socket.on('id1', function (data) {
        console.log("mensage from websocket: " + data);
    });

    function emit(id, message) {
        $.get('/emit/' + id +  '/' + message);
    }
</script>
</body>
</html>

Now we need to add another route to our Silex application

use Symfony\Component\HttpFoundation\Response;

$app->get('/emit/{id}/{message}', function ($id, $message) use ($app) {
    $s = curl_init();
    curl_setopt($s, CURLOPT_URL, "http://localhost:26300/emit/{$id}/{$message}");
    curl_setopt($s, CURLOPT_RETURNTRANSFER, true);
    $content = curl_exec($s);
    $status = curl_getinfo($s, CURLINFO_HTTP_CODE);
    curl_close($s);

    return new Response($content, $status);
});

And that’s all. Our Request from Silex arrives to WebSocket emmiter using a “secure” layer. OK, now you can said: yes, but anybody can connect to the WebSocket server and listen to ‘id1′ chanel, without any restriction. Yes, it’s true. But here you can use different solutions to ensure privacy. For example you can use a “non-obvious” chanel name based on cryptografic funcions. It’s not 100% secure, but it’s the same security layer than the standard session based security mechanism. If we know the cookie name we can perform a session hijacking attack and gain access to secure areas (without knowing the login credentials). We can generate chanel names like this: 7265cfe8fe3daa4c5069d609a0312dd2 with our Silex Application and send to the browser with an AJAX request.

I’ve created an small screencast to see the prototype in action. (source code in my github account)
In the screencast we can see how to install the prototype from github, install PHP’s vendors and the node js modules. We also can see how websocket works with two browser instances, and how to send messages directly accesing to Express application using localhost interface (and an error when I try to reach to Express server using a different network interface)

What do you think? Do you have another solution?

Playing with HTML5. Building a simple pool of WebWokers

Today I’m playing with the HTML5’s WebWorkers. Since our JavaScript code runs within a single thread in our WebBrowser, heavy scripts can lock the execution of our code. HTML5 gives us one tool called WebWorkers to allow us to run different threads within our Application.

Today I’m playing with one small example (that’s just an experiment). I want to create a pool of WebWebworkers and use them as a simple queue.
The usage of the library is similar than the usage of WebWorkers. The following code shows how to start the pool with 10 instances of our worker “js/worker.js”

    // new worker pool with 10 instances of the worker
    var pool = new WorkerPool('js/worker.js', 10);

    // register callback to worker's onmessage event
    pool.registerOnMessage(function (e) {
        console.log("Received (from worker): ", e.data);
    });

“js/worker.js” is a standard WebWorker. In this example our worker perform XHR request to a API server (in this case one Silex application)

importScripts('ajax.js');

self.addEventListener('message', function (e) {
    var data = e.data;

    switch (data.method) {
        case 'GET':
            getRequest(data.resource, function(xhr) {
                self.postMessage({status: xhr.status, responseText: xhr.responseText});
            });
            break;
    }
}, false);

WebWorkers runs in different scope than a traditional browser application. Not all JavaScript objects are available in the webworker scpope. For example we cannot access to “window” and DOM elements, but we can use XMLHttpRequest. In our experimente we’re going to preform XHR requests from the webworker.

The library creates a queue with the variable number of workers:

var WorkerPool;

WorkerPool = (function () {
    var pool = {};
    var poolIds = [];

    function WorkerPool(worker, numberOfWorkers) {
        this.worker = worker;
        this.numberOfWorkers = numberOfWorkers;

        for (var i = 0; i < this.numberOfWorkers; i++) {
            poolIds.push(i);
            var myWorker = new Worker(worker);

            +function (i) {
                myWorker.addEventListener('message', function (e) {
                    var data = e.data;
                    console.log("Worker #" + i + " finished. status: " + data.status);
                    pool[i].status = true;
                    poolIds.push(i);
                });
            }(i);

            pool[i] = {status: true, worker: myWorker};
        }

        this.getFreeWorkerId = function (callback) {
            if (poolIds.length > 0) {
                return callback(poolIds.pop());
            } else {
                var that = this;
                setTimeout(function () {
                    that.getFreeWorkerId(callback);
                }, 100);
            }
        }
    }

    WorkerPool.prototype.postMessage = function (data) {
        this.getFreeWorkerId(function (workerId) {
            pool[workerId].status = false;
            var worker = pool[workerId].worker;
            console.log("postMessage with worker #" + workerId);
            worker.postMessage(data);
        });
    };

    WorkerPool.prototype.registerOnMessage = function (callback) {
        for (var i = 0; i < this.numberOfWorkers; i++) {
            pool[i].worker.addEventListener('message', callback);
        }
    };

    WorkerPool.prototype.getFreeIds = function () {
        return poolIds;
    };

    return WorkerPool;
})();

The API server is a simple Silex application. This application also enables cross origin (CORS). You can read about it here.

use Silex\Application;
use Symfony\Component\HttpFoundation\Request;
use Symfony\Component\HttpFoundation\Response;

$app = new Application();

$app->get('/hello', function () use ($app) {
    error_log("GET /hello");
    sleep(2); // emulate slow process
    return $app->json(['method' => 'GET', 'response' => 'OK']);
});

$app->after(function (Request $request, Response $response) {
    $response->headers->set('Access-Control-Allow-Origin', '*');
});

$app->run();

You can see the whole code in my github account.

Here one small screencast to see the application in action.

Enabling CORS in a RESTFull Silex server, working with a phonegap/cordova applications

This days I’m working with phonegap/cordova projects. I’m using topcoat and AngularJs to build the client side and Silex for the backend. Cordova applications are “diferent” than a common web application. Our client side is normally located inside our mobile device (it’s also possible to use remote webviews). Our cordova application must speak with our backend. The easiest way to perform this operation is to use a REST. AngularJS has a great tool to connect with RESTFull resources. Silex is also great to build RESTFull services. I wrote a couple of posts about it.

With the first request form our AngularJS application (into our android/iphone device) to our Silex application, we will face with CORS. We cannot perform a request from our “local” phonegap/cordova application to our remote WebServer. We cannot do it if we don’t allow it explictily. With Silex it’s pretty straight forward to do it. We can use the event dispatcher and change the request with after handler.

$app->after(function (Request $request, Response $response) {
    $response->headers->set('Access-Control-Allow-Origin', '*');
});

We can do more strict, setting also “Access-Control-Allow-Methods” and “Access-Control-Allow-Headers” headers but only with this header we can work properly with our RESTFull Silex application from our phonegap/cordova application.

How to run a Web Server from a PHP application

Normally we deploy our PHP applications in a webserver (such as apache, nginx, …). I used to have one apache webserver in my personal computer to play with my applications, but from time to now I preffer to use PHP’s built-in webserver for my experiments. It’s really simple. Just run:

php -S 0.0.0.0:8080

and we’ve got one PHP webserver at our current directory. With another languages (such as node.js, Python) we can start a Web Server from our application. For example with node.js:

var http = require('http');
http.createServer(function (req, res) {
  res.writeHead(200, {'Content-Type': 'text/plain'});
  res.end('Hello World\n');
}).listen(8080, '0.0.0.0');
console.log('Server running at http://0.0.0.0:8080');

With PHP we cannot do it. Sure? That assertion isn’t really true. We can do it. I’ve just create one small library to do it in two different ways. First running the built-in web server and also running one React web server.

I want to share the same interface to start the server. In this implementation we will register one callback to handle incomming requests. This callback will accept a Symfony\Component\HttpFoundation\Request and it will return a Symfony\Component\HttpFoundation\Response. Then we will start our server listening to one port and we will run our callback per Request (a simple implementeation of the reactor pattern)

We will create a static factory to create the server

namespace G\HttpServer;
use React;

class Builder
{
    public static function createBuiltInServer($requestHandler)
    {
        $server = new BuiltInServer();
        $server->registerHandler($requestHandler);

        return $server;
    }

    public static function createReactServer($requestHandler)
    {
        $loop   = React\EventLoop\Factory::create();
        $socket = new React\Socket\Server($loop);

        $server = new ReactServer($loop, $socket);
        $server->registerHandler($requestHandler);

        return $server;
    }
}

Each server (BuiltIn, and React) has its own implementation.

And basically that’s all. We can run a simple webserver with the built-in server

use G\HttpServer\Builder;
use Symfony\Component\HttpFoundation\Request;

Builder::createBuiltInServer(function (Request $request) {
        return "Hello " . $request->get('name');
    })->listen(1337);

Or the same thing but with React

use G\HttpServer\Builder;
use Symfony\Component\HttpFoundation\Request;

Builder::createReactServer(function (Request $request) {
        return "Hello " . $request->get('name');
    })->listen(1337);

As you can see our callback handles one Request and returns one Response (The typical HttpKernel), because of that we also can run one Silex application:
With built-in:

use G\HttpServer\Builder;
use Symfony\Component\HttpFoundation\Request;

$app = new Silex\Application();

$app->get('/', function () {
        return 'Hello';
    });

$app->get('/hello/{name}', function ($name) {
        return 'Hello ' . $name;
    });

Builder::createBuiltInServer(function (Request $request) use ($app) {
        return $app->handle($request);
    })->listen(1337);

And the same with React:

use G\HttpServer\Builder;
use Symfony\Component\HttpFoundation\Request;

$app = new Silex\Application();

$app->get('/', function () {
        return 'Hello';
    });

$app->get('/hello/{name}', function ($name) {
        return 'Hello ' . $name;
    });

Builder::createReactServer(function (Request $request) use ($app) {
        return $app->handle($request);
    })->listen(1337);

As an exercise I also have created one small benchmark (with both implementations) with apache ab running 100 request with a 10 request at the same time. Here you can see the outcomes.

  builtin react
Simple response
ab -n 100 -c 10 http://localhost:1337/
Time taken for tests 0.878 seconds 0.101 seconds
Requests per second (mean) 113.91 [#/sec] 989.33 [#/sec]
Time per request (mean) 87.791 [ms] 10.108 [ms]
Time per request (mean across all concurrent requests) 8.779 [ms] 1.011 [ms]
Transfer rate 21.02 [Kbytes/sec] 112.07 [Kbytes/sec]
Silex application
ab -n 100 -c 10 http://localhost:1337/
Time taken for tests 2.241 seconds 0.247 seconds
Requests per second (mean) 44.62 [#/sec] 405.29 [#/sec]
Time per request 224.119 [ms] 24.674 [ms]
Time per request (mean across all concurrent requests) 22.412 [ms] 2.467 [ms]
Transfer rate 10.89 [Kbytes/sec] 75.60 [Kbytes/sec]
ab -n 100 -c 10 http://localhost:1337/hello/gonzalo
Time taken for tests 2.183 seconds 0.271 seconds
Requests per second (mean) 45.81 [#/sec] (mean) 369.67 [#/sec]
Time per request (mean) 218.290 [ms] (mean) 27.051 [ms]
Time per request (mean across all concurrent requests) 21.829 [ms] 2.705 [ms]
Transfer rate 11.54 [Kbytes/sec] 71.84 [Kbytes/sec]

Built-in web server is not suitable for production environments, but React would be a useful tool in some cases (maybe not good for running Facebook but good enough for punctual situations).

Library is available at github and also you can use it with composer

Playing with event dispatcher and Silex. Sending logs to a remote server.

Today I continue playing with event dispatcher and Silex. Now I want to send a detailed log of our Kernel events to a remote server. We can do it something similar with Monolog, but I want to implement one working example hacking a little bit the event dispatcher. Basically we’re going to create one Logger class (implementing PSR-3 of course)

namespace G;

use Psr\Log\LoggerInterface;
use Psr\Log\LogLevel;

class Logger implements LoggerInterface
{
    private $socket;

    public function __construct($socket)
    {
        $this->socket = $socket;
    }

    function __destruct()
    {
        @fclose($this->socket);
    }

    public function emergency($message, array $context = array())
    {
        $this->sendLog($message, $context, LogLevel::EMERGENCY);
    }

    public function alert($message, array $context = array())
    {
        $this->sendLog($message, $context, LogLevel::ALERT);
    }

    public function critical($message, array $context = array())
    {
        $this->sendLog($message, $context, LogLevel::CRITICAL);
    }

    public function error($message, array $context = array())
    {
        $this->sendLog($message, $context, LogLevel::ERROR);
    }

    public function warning($message, array $context = array())
    {
        $this->sendLog($message, $context, LogLevel::WARNING);
    }

    public function notice($message, array $context = array())
    {
        $this->sendLog($message, $context, LogLevel::NOTICE);
    }

    public function info($message, array $context = array())
    {
        $this->sendLog($message, $context, LogLevel::INFO);
    }

    public function debug($message, array $context = array())
    {
        $this->sendLog($message, $context, LogLevel::DEBUG);
    }

    public function log($level, $message, array $context = array())
    {
        $this->sendLog($message, $context, $level);
    }

    private function sendLog($message, array $context = array(), $level = LogLevel::INFO)
    {
        $data = serialize([$message, $context, $level]);
        @fwrite($this->socket, "{$data}\n");
    }
}

As you can see our Logger class send logs to a remote server, with a socket passed within the constructor.
We also need one Service Provider called LoggerServiceProvider to integrate our Logger instance into our Silex application.

namespace G;

use Silex\Application;
use Silex\ServiceProviderInterface;

class LoggerServiceProvider implements ServiceProviderInterface
{
    private $socket;

    public function __construct($socket)
    {
        $this->socket = $socket;
    }

    public function register(Application $app)
    {
        $app['remoteLogger'] = $app->share(
            function () use ($app) {
                return new Logger($this->socket);
            }
        );
    }

    public function boot(Application $app)
    {
    }
}

And now the last part is our Silex application:

use G\LoggerServiceProvider;
use G\Silex\Application;
use Symfony\Component\HttpFoundation\Request;
use Symfony\Component\HttpKernel;
use Symfony\Component\HttpKernel\Event;

$app = new Application();
$app->register(new LoggerServiceProvider(stream_socket_client('tcp://localhost:4000')));

$app->on(HttpKernel\KernelEvents::REQUEST, function (Event\GetResponseEvent $event) use ($app) {
        $app->getLogger()->info($event->getName());
    }
);

$app->on(HttpKernel\KernelEvents::CONTROLLER, function (Event\FilterControllerEvent $event) use ($app) {
        $app->getLogger()->info($event->getName());
    }
);

$app->on(HttpKernel\KernelEvents::TERMINATE, function (Event\PostResponseEvent $event) use ($app) {
        $app->getLogger()->info($event->getName());
    }
);

$app->on(HttpKernel\KernelEvents::EXCEPTION, function (Event\GetResponseForExceptionEvent $event) use ($app) {
        $app->getLogger()->critical($event->getException()->getMessage());
    }
);

$app->get('/', function () {
    return 'Hello';
});

$app->run();

As we can see the event dispacher send each event to a remote server (in this example: tcp://localhost:4000). Now we only need a tcp server to handle those sockets. We can use different tools and libraries to do that. In this example we’re going to use React.

use React\EventLoop\Factory;
use React\Socket\Server;

$loop   = Factory::create();
$socket = new Server($loop);

$socket->on('connection', function (\React\Socket\Connection $conn){
    $unique = uniqid();
    $conn->on('data', function ($data) use ($unique) {
            list($message, $context, $level) = \unserialize($data);
            echo date("d/m/Y H:i:s")."::{$level}::{$unique}::{$message}" . PHP_EOL;
        });
});

echo "Socket server listening on port 4000." .PHP_EOL;
echo "You can connect to it by running: telnet localhost 4000" . PHP_EOL;

$socket->listen(4000);
$loop->run();

Now we only need to start our servers:
our silex one

php -S 0.0.0.0:8080 -t www

and the tcp server

php app/server.php

One screencast showing the prototype in action:

You can see the full code in my github account.

Using the event dispatcher in a Silex application

Symfony has one component called The Event Dispatcher. This component is one implementation of Mediator pattern and it’s widely used in modern frameworks, such as Symfony. Silex, as a part of Symfony, also uses this component and we can easily use it in our projects. Let me show you one little example. Imagine one simple route in Silex to create one png file containing one text:

$app->get("/gd/{text}", function($text) {
    $path = "/tmp/qr.png." . uniqid();
    $im = imagecreate(90, 30);
    $background = imagecolorallocate($im, 255, 255, 255);
    $color = imagecolorallocate($im, 0, 0, 0);
    imagestring($im, 5, 5, 5,  $text, $color);
    imagepng($im, $path);
    imagedestroy($im);
    return $app->sendFile($path);
});

It works, but there’s one mistake. We need to unlink our temporally file $path, but where? We need do if after “return $app->sendFile($path);” but it’s not possible.

$app->get("/gd/{text}", function($text) {
    $path = "/tmp/qr.png." . uniqid();
    $im = imagecreate(90, 30);
    $background = imagecolorallocate($im, 255, 255, 255);
    $color = imagecolorallocate($im, 0, 0, 0);
    imagestring($im, 5, 5, 5,  $text, $color);
    imagepng($im, $path);
    imagedestroy($im);
    return $app->sendFile($path, 200, ['Content-Type' => 'image/png']);;
    unlink($path); // unreachable code
});

We can use BinaryFileResponse instead of the helper function “sendFile”, but there’s one smarter solution: The event dispatcher.

use Symfony\Component\HttpKernel\KernelEvents;

$app->get("/gd/{text}", function($text) use (app) {
    $im = imagecreate(90, 30);
    $path = "/tmp/qr.png." . uniqid();
    $background = imagecolorallocate($im, 255, 255, 255);
    $color = imagecolorallocate($im, 0, 0, 0);
    imagestring($im, 5, 5, 5,  $text, $color);
    imagepng($im, $path);
    imagedestroy($im);

    $app['dispatcher']->addListener(KernelEvents::TERMINATE, function() use ($path) {
        unlink($path);
    });

    return $app->sendFile($path, 200, ['Content-Type' => 'image/png']);
});

(Updated! thanks to Hakin’s recommendation)
Or even better using Silex’s Filters. In this case we after or finish. In fact those filters are nothing more than an elegant way to speak to the event dispatcher.


$app->get("/gd/{text}", function($text) use (app) {
    $im = imagecreate(90, 30);
    $path = "/tmp/qr.png." . uniqid();
    $background = imagecolorallocate($im, 255, 255, 255);
    $color = imagecolorallocate($im, 0, 0, 0);
    imagestring($im, 5, 5, 5,  $text, $color);
    imagepng($im, $path);
    imagedestroy($im);

    $app->after(function() use ($path) {
        unlink($path);
    });

    return $app->sendFile($path, 200, ['Content-Type' => 'image/png']);
});

We also can use the generic function to add events to the event listener:

use Symfony\Component\HttpKernel\KernelEvents;

$app->get("/gd/{text}", function($text) use (app) {
    $im = imagecreate(90, 30);
    $path = "/tmp/qr.png." . uniqid();
    $background = imagecolorallocate($im, 255, 255, 255);
    $color = imagecolorallocate($im, 0, 0, 0);
    imagestring($im, 5, 5, 5,  $text, $color);
    imagepng($im, $path);
    imagedestroy($im);

    $app->on(KernelEvents::TERMINATE, function() use ($path) {
        unlink($path);
    });

    return $app->sendFile($path, 200, ['Content-Type' => 'image/png']);
});

Now our temporally file will be deleted once a response is sent. Life is simpler with event dispatcher :)

Creating QR codes with PHP and Silex

Today we’re going to play with QR codes and how to use them within a Silex application using one Service Provider. First we need a QR code generator. If we find in Packagist we can see various libraries. We are going to use the library: endroid/qrcode.

We are not going to modify endroid/qrcode, because of that we will create a wrapper. This wrapper will receive in the constructor one instance of endroid/qrcode. It’s responsability will be to take one QrCode object and generate a Symfony\Component\HttpFoundation\Response with our QR code and the properly headers. Here you can see the unit tests of our QrWrapper:

use Symfony\Component\HttpFoundation\Response;
use G\QrWrapper;

class QrWrapperTest extends PHPUnit_Framework_TestCase
{
    public function testObjectInit()
    {
        $qrCode = $this->getMockBuilder('Endroid\QrCode\QrCode')
                ->disableOriginalConstructor()
                ->getMock();

        $wrapper = new QrWrapper($qrCode);

        $this->assertInstanceOf('G\QrWrapper', $wrapper);
    }

    public function testGetResponseWithDefaultParameters()
    {
        $qrCode = $this->getMockBuilder('Endroid\QrCode\QrCode')
                ->disableOriginalConstructor()
                ->getMock();

        $qrCode->expects($this->any())->method('get')->will($this->returnValue("hello"));
        $wrapper = new QrWrapper($qrCode);

        $response = $wrapper->getResponse();

        $this->assertInstanceOf('Symfony\Component\HttpFoundation\Response', $response);
        $this->assertEquals("hello", $response->getContent());
        $this->assertEquals("image/png", $response->headers->get('Content-Type'));
    }

    public function testGetResponseForJpg()
    {
        $qrCode = $this->getMockBuilder('Endroid\QrCode\QrCode')
                ->disableOriginalConstructor()
                ->getMock();

        $qrCode->expects($this->any())->method('get')->will($this->returnValue("hello"));
        $wrapper = new QrWrapper($qrCode);
        $wrapper->setImageType('jpg');

        $response = $wrapper->getResponse();

        $this->assertInstanceOf('Symfony\Component\HttpFoundation\Response', $response);
        $this->assertEquals("hello", $response->getContent());
        $this->assertEquals("image/jpeg", $response->headers->get('Content-Type'));
    }

    public function testGetResponseForJpeg()
    {
        $qrCode = $this->getMockBuilder('Endroid\QrCode\QrCode')
                ->disableOriginalConstructor()
                ->getMock();

        $qrCode->expects($this->any())->method('get')->will($this->returnValue("hello"));
        $wrapper = new QrWrapper($qrCode);
        $wrapper->setImageType('jpeg');

        $response = $wrapper->getResponse();

        $this->assertInstanceOf('Symfony\Component\HttpFoundation\Response', $response);
        $this->assertEquals("hello", $response->getContent());
        $this->assertEquals("image/jpeg", $response->headers->get('Content-Type'));
    }

    public function testReusingResponse()
    {
        $qrCode = $this->getMockBuilder('Endroid\QrCode\QrCode')
                ->disableOriginalConstructor()
                ->getMock();

        $qrCode->expects($this->any())->method('get')->will($this->returnValue("hello"));
        $wrapper = new QrWrapper($qrCode);

        $response = new Response('foo');
        $response->headers->set('xxx', 'gonzalo');

        $response = $wrapper->getResponse($response);

        $this->assertEquals("hello", $response->getContent());
        $this->assertEquals("image/png", $response->headers->get('Content-Type'));
        $this->assertEquals("gonzalo", $response->headers->get('xxx'));
    }
}

Now we will create the ServiceProvider. We only need to implement ServiceProviderInterface

use Silex\Application;
use Silex\ServiceProviderInterface;
use Endroid\QrCode\QrCode;

class QrServiceProvider implements ServiceProviderInterface
{
    public function register(Application $app)
    {
        $app['qrCode'] = $app->protect(function ($text, $size = null) use ($app) {
            $default = $app['qr.defaults'];

            $qr = new QrWrapper(new QrCode());
            $qr->setText($text);
            $qr->setPadding($default['padding']);
            $qr->setSize(is_null($size) ? $default['size'] : $size);
            $qr->setImageType($default['imageType']);

            return $qr;
        });
    }

    public function boot(Application $app)
    {
    }
}

And that’s all. Now we can use our service provider within one Silex Application:

use Silex\Application;
use G\QrServiceProvider;

$app = new Application();

$app->register(new QrServiceProvider(), [
    'qr.defaults' => [
        'padding'   => 5, // default: 0
        'size'      => 200,
        'imageType' => 'png', // png, gif, jpeg, wbmp (default: png)
    ]
]);

$app->get("/qr/base64/{text}", function($text) use ($app) {
    return $app['qrCode'](base64_decode($text))->getResponse();
});

$app->get("/qr/{text}", function($text) use ($app) {
    return $app['qrCode']($text)->getResponse();
});

$app->run();

You can fetch the full code in github and also use it with composer

Bundles in Silex using Stack

In the last Desymfony conference I was speaking with Luis Cordova and he introduced me “Stack” (I must admit Stack was in my to-study-list but only marked as favorite). The idea behind Stack is really cool. (In fact every project where Igor Wiedler appears is brilliant, even the chicken one :)).

Nowadays almost every modern framework/applications implements HttpKernelInterface (Symfony, Laravel, Drupal, Silex, Yolo and even the framework that I’m working in ;)) and we can build complex applications mixing different components and decorate our applications with an elegant syntax.

The first thing than come to my mind after studying Stack is to join different Silex applications in a similar way than Symfony (the full stack framework) uses bundles. And the best part of this idea is that it’s pretty straightforward. Let me show you one example:

Imagine that we’re working with one application with a blog and one API. In this case our blog and our API are Silex applications (but they can be one Symfony application and one Silex application for example).

That’s our API application:

use Silex\Application;

$app = new Application();
$app->get('/', function () {
        return "Hello from API";
    });

$app->run();

And here our blog application:

use Silex\Application;

$app = new Application();
$app->get('/', function () {
        return "Hello from Blog";
    });

$app->run();

We can organize our application using mounted controllers or even using RouteCollections but today we’re going to use Stack and it’s cool url-map.

First we are going to create our base application. To do this we’re going to implement the simplest Kernel in the world, that’s answers with “Hello” to every request:

use Symfony\Component\HttpKernel\HttpKernelInterface;
use Symfony\Component\HttpFoundation\Request;
use Symfony\Component\HttpFoundation\Response;

class MyKernel implements HttpKernelInterface
{
    public function handle(Request $request, $type = HttpKernelInterface::MASTER_REQUEST, $catch = true)
    {
        return new Response("Hello");
    }
}

Stack needs HttpKernelInterface and Silex\Application implements this interface, so we can change our Silex applications to return the instance instead to run the application:

// app/api.php
use Silex\Application;

$app = new Application();
$app->get('/', function () {
        return "Hello from API";
    });

return $app;
// app/blog.php
use Silex\Application;

$app = new Application();
$app->get('/', function () {
        return "Hello from API";
    });

return $app;

And now we will attach those two Silex applications to our Kernel:

use Symfony\Component\HttpFoundation\Request;

$app = (new Stack\Builder())
    ->push('Stack\UrlMap', [
            "/blog" => include __DIR__ . '/app/blog.php',
            "/api" => include __DIR__ . '/app/api.php'
        ])->resolve(new MyKernel());

$request = Request::createFromGlobals();

$response = $app->handle($request);
$response->send();

$app->terminate($request, $response);

And that’s all. I don’t know what you think but with Stack one big window just opened in my mind. Cool, isn’t it?

You can see this working example in my github

Follow

Get every new post delivered to your Inbox.

Join 953 other followers
