Working with SAPUI5 locally (part 3). Adding more services in Docker

In the previous project we moved one project to docker. The idea was to move exactly the same functionality (even without touching anything within the source code). Now we’re going to add more services. Yes, I know, it looks like overenginering (it’s exactly overenginering, indeed), but I want to build something with different services working together. Let start.

We’re going to change a little bit our original project. Now our frontend will only have one button. This button will increment the number of clicks but we’re going to persists this information in a PostgreSQL database. Also, instead of incrementing the counter in the backend, our backend will emit one event to a RabbitMQ message broker. We’ll have one worker service listening to this event and this worker will persist the information. The communication between the worker and the frontend (to show the incremented value), will be via websockets.

With those premises we are going to need:

  • Frontend: UI5 application
  • Backend: PHP/lumen application
  • Worker: nodejs application which is listening to a RabbitMQ event and serving the websocket server (using socket.io)
  • Nginx server
  • PosgreSQL database.
  • RabbitMQ message broker.

As the previous examples, our PHP backend will be server via Nginx and PHP-FPM.

Here we can see to docker-compose file to set up all the services

version: '3.4'

services:
  nginx:
    image: gonzalo123.nginx
    restart: always
    ports:
    - "8080:80"
    build:
      context: ./src
      dockerfile: .docker/Dockerfile-nginx
    volumes:
    - ./src/backend:/code/src
    - ./src/.docker/web/site.conf:/etc/nginx/conf.d/default.conf
    networks:
    - app-network
  api:
    image: gonzalo123.api
    restart: always
    build:
      context: ./src
      dockerfile: .docker/Dockerfile-lumen-dev
    environment:
      XDEBUG_CONFIG: remote_host=${MY_IP}
    volumes:
    - ./src/backend:/code/src
    networks:
    - app-network
  ui5:
    image: gonzalo123.ui5
    ports:
    - "8000:8000"
    restart: always
    volumes:
    - ./src/frontend:/code/src
    build:
      context: ./src
      dockerfile: .docker/Dockerfile-ui5
    networks:
    - app-network
  io:
    image: gonzalo123.io
    ports:
    - "9999:9999"
    restart: always
    volumes:
    - ./src/io:/code/src
    build:
      context: ./src
      dockerfile: .docker/Dockerfile-io
    networks:
    - app-network
  pg:
    image: gonzalo123.pg
    restart: always
    ports:
    - "5432:5432"
    build:
      context: ./src
      dockerfile: .docker/Dockerfile-pg
    environment:
      POSTGRES_PASSWORD: ${POSTGRES_PASSWORD}
      POSTGRES_USER: ${POSTGRES_USER}
      POSTGRES_DB: ${POSTGRES_DB}
      PGDATA: /var/lib/postgresql/data/pgdata
    networks:
    - app-network
  rabbit:
    image: rabbitmq:3-management
    container_name: gonzalo123.rabbit
    restart: always
    ports:
    - "15672:15672"
    - "5672:5672"
    environment:
      RABBITMQ_ERLANG_COOKIE:
      RABBITMQ_DEFAULT_VHOST: /
      RABBITMQ_DEFAULT_USER: ${RABBITMQ_DEFAULT_USER}
      RABBITMQ_DEFAULT_PASS: ${RABBITMQ_DEFAULT_PASS}
    networks:
    - app-network
networks:
  app-network:
    driver: bridge

We’re going to use the same docker files than in the previous post but we also need new ones for worker, database server and message queue:

Worker:

FROM node:alpine

EXPOSE 8000

WORKDIR /code/src
COPY ./io .
RUN npm install
ENTRYPOINT ["npm", "run", "serve"]

The worker script is simple script that serves the socket.io server and emits a websocket within every message to the RabbitMQ queue.

var amqp = require('amqp'),
  httpServer = require('http').createServer(),
  io = require('socket.io')(httpServer, {
    origins: '*:*',
  }),
  pg = require('pg')
;

require('dotenv').config();
var pgClient = new pg.Client(process.env.DB_DSN);

rabbitMq = amqp.createConnection({
  host: process.env.RABBIT_HOST,
  port: process.env.RABBIT_PORT,
  login: process.env.RABBIT_USER,
  password: process.env.RABBIT_PASS,
});

var sql = 'SELECT clickCount FROM docker.clicks';

// Please don't do this. Use lazy connections
// I'm 'lazy' to do it in this POC 🙂
pgClient.connect(function(err) {
  io.on('connection', function() {
    pgClient.query(sql, function(err, result) {
      var count = result.rows[0]['clickcount'];
      io.emit('click', {count: count});
    });

  });

  rabbitMq.on('ready', function() {
    var queue = rabbitMq.queue('ui5');
    queue.bind('#');

    queue.subscribe(function(message) {
      pgClient.query(sql, function(err, result) {
        var count = parseInt(result.rows[0]['clickcount']);
        count = count + parseInt(message.data.toString('utf8'));
        pgClient.query('UPDATE docker.clicks SET clickCount = $1', [count],
          function(err) {
            io.emit('click', {count: count});
          });
      });
    });
  });
});

httpServer.listen(process.env.IO_PORT);

Database server:

FROM postgres:9.6-alpine
COPY pg/init.sql /docker-entrypoint-initdb.d/

As we can see we’re going to generate the database estructure in the first build

CREATE SCHEMA docker;

CREATE TABLE docker.clicks (
clickCount numeric(8) NOT NULL
);

ALTER TABLE docker.clicks
OWNER TO username;

INSERT INTO docker.clicks(clickCount) values (0);

With the RabbitMQ server we’re going to use the official docker image so we don’t need to create one Dockerfile

We also have changed a little bit our Nginx configuration. We want to use Nginx to serve backend and also socket.io server. That’s because we don’t want to expose different ports to internet.

server {
    listen 80;
    index index.php index.html;
    server_name localhost;
    error_log  /var/log/nginx/error.log;
    access_log /var/log/nginx/access.log;
    root /code/src/www;

    location /socket.io/ {
        proxy_http_version 1.1;
        proxy_set_header Upgrade $http_upgrade;
        proxy_set_header Connection "upgrade";
        proxy_pass "http://io:9999";
    }

    location / {
        try_files $uri $uri/ /index.php?$query_string;
    }

    location ~ \.php$ {
        try_files $uri =404;
        fastcgi_split_path_info ^(.+\.php)(/.+)$;
        fastcgi_pass api:9000;
        fastcgi_index index.php;
        include fastcgi_params;
        fastcgi_param SCRIPT_FILENAME $document_root$fastcgi_script_name;
        fastcgi_param PATH_INFO $fastcgi_path_info;
    }
}

To avoid CORS issues we can also use SCP destination (the localneo proxy in this example), to serve socket.io also. So we need to:

  • change our neo-app.json file
  • "routes": [
        ...
        {
          "path": "/socket.io",
          "target": {
            "type": "destination",
            "name": "SOCKETIO"
          },
          "description": "SOCKETIO"
        }
      ],


    And basically that’s all. Here also we can use a “production” docker-copose file without exposing all ports and mapping the filesystem to our local machine (useful when we’re developing)

    version: '3.4'

    services:
      nginx:
        image: gonzalo123.nginx
        restart: always
        build:
          context: ./src
          dockerfile: .docker/Dockerfile-nginx
        networks:
        - app-network
      api:
        image: gonzalo123.api
        restart: always
        build:
          context: ./src
          dockerfile: .docker/Dockerfile-lumen
        networks:
        - app-network
      ui5:
        image: gonzalo123.ui5
        ports:
        - "80:8000"
        restart: always
        volumes:
        - ./src/frontend:/code/src
        build:
          context: ./src
          dockerfile: .docker/Dockerfile-ui5
        networks:
        - app-network
      io:
        image: gonzalo123.io
        restart: always
        build:
          context: ./src
          dockerfile: .docker/Dockerfile-io
        networks:
        - app-network
      pg:
        image: gonzalo123.pg
        restart: always
        build:
          context: ./src
          dockerfile: .docker/Dockerfile-pg
        environment:
          POSTGRES_PASSWORD: ${POSTGRES_PASSWORD}
          POSTGRES_USER: ${POSTGRES_USER}
          POSTGRES_DB: ${POSTGRES_DB}
          PGDATA: /var/lib/postgresql/data/pgdata
        networks:
        - app-network
      rabbit:
        image: rabbitmq:3-management
        restart: always
        environment:
          RABBITMQ_ERLANG_COOKIE:
          RABBITMQ_DEFAULT_VHOST: /
          RABBITMQ_DEFAULT_USER: ${RABBITMQ_DEFAULT_USER}
          RABBITMQ_DEFAULT_PASS: ${RABBITMQ_DEFAULT_PASS}
        networks:
        - app-network
    networks:
      app-network:
        driver: bridge


    And that’s all. The full project is available in my github account

    Advertisements

    Working with SAPUI5 locally (part 2). Now with docker

    In the first part I spoke about how to build our working environment to work with UI5 locally instead of using WebIDE. Now, in this second part of the post, we’ll see how to do it using docker to set up our environment.

    I’ll use docker-compose to set up the project. Basically, as I explain in the first part, the project has two parts. One backend and one frontned. We’re going to use exactly the same code for the frontend and for the backend.

    The frontend is build over a localneo. As it’s a node application we’ll use a node:alpine base host

    FROM node:alpine

    EXPOSE 8000

    WORKDIR /code/src
    COPY ./frontend .
    RUN npm install
    ENTRYPOINT ["npm", "run", "serve"]


    In docker-compose we only need to map the port that we´ll expose in our host and since we want this project in our depelopemet process, we also will map the volume to avoid to re-generate our container each time we change the code.

    ...
      ui5:
        image: gonzalo123.ui5
        ports:
        - "8000:8000"
        restart: always
        build:
          context: ./src
          dockerfile: .docker/Dockerfile-ui5
        volumes:
        - ./src/frontend:/code/src
        networks:
        - api-network


    The backend is a PHP application. We can set up a PHP application using different architectures. In this project we’ll use nginx and PHP-FPM.

    for nginx we’ll use the following Dockerfile

    FROM  nginx:1.13-alpine

    EXPOSE 80

    COPY ./.docker/web/site.conf /etc/nginx/conf.d/default.conf
    COPY ./backend /code/src


    And for the PHP host the following one (with xdebug to enable debugging and breakpoints):

    FROM php:7.1-fpm

    ENV PHP_XDEBUG_REMOTE_ENABLE 1

    RUN apt-get update && apt-get install -my \
        git \
        libghc-zlib-dev && \
        apt-get clean

    RUN apt-get install -y libpq-dev \
        && docker-php-ext-configure pgsql -with-pgsql=/usr/local/pgsql \
        && docker-php-ext-install pdo pdo_pgsql pgsql opcache zip

    RUN curl -sS https://getcomposer.org/installer | php -- --install-dir=/usr/local/bin --filename=composer

    RUN composer global require "laravel/lumen-installer"
    ENV PATH ~/.composer/vendor/bin:$PATH

    COPY ./backend /code/src


    And basically that’s all. Here the full docker-compose file

    version: '3.4'

    services:
      nginx:
        image: gonzalo123.nginx
        restart: always
        ports:
        - "8080:80"
        build:
          context: ./src
          dockerfile: .docker/Dockerfile-nginx
        volumes:
        - ./src/backend:/code/src
        - ./src/.docker/web/site.conf:/etc/nginx/conf.d/default.conf
        networks:
        - api-network
      api:
        image: gonzalo123.api
        restart: always
        build:
          context: ./src
          dockerfile: .docker/Dockerfile-lumen-dev
        environment:
          XDEBUG_CONFIG: remote_host=${MY_IP}
        volumes:
        - ./src/backend:/code/src
        networks:
        - api-network
      ui5:
        image: gonzalo123.ui5
        ports:
        - "8000:8000"
        restart: always
        build:
          context: ./src
          dockerfile: .docker/Dockerfile-ui5
        networks:
        - api-network

    networks:
      api-network:
        driver: bridge


    If we want to use this project you only need to:

    • clone the repo fron github
    • run ./ui5 up

    With this configuration we’re exposing two ports 8080 for the frontend and 8000 for the backend. We also are mapping our local filesystem to containers to avoid to regenerate our containers each time we change the code.

    We also can have a variation. A “production” version of our docker-compose file. I put production between quotation marks because normally we aren’t going to use localneo as a production server (please don’t do it). We’ll use SCP to host the frontend.

    This configuration is just an example without filesystem mapping, without xdebug in the backend and without exposing the backend externally (Only the frontend can use it)

    version: '3.4'

    services:
      nginx:
        image: gonzalo123.nginx
        restart: always
        build:
          context: ./src
          dockerfile: .docker/Dockerfile-nginx
        networks:
        - api-network
      api:
        image: gonzalo123.api
        restart: always
        build:
          context: ./src
          dockerfile: .docker/Dockerfile-lumen
        networks:
        - api-network
      ui5:
        image: gonzalo123.ui5
        ports:
        - "8000:8000"
        restart: always
        build:
          context: ./src
          dockerfile: .docker/Dockerfile-ui5
        networks:
        - api-network

    networks:
      api-network:
        driver: bridge


    And that’s all. You can see the all the source code in my github account

    Playing with Docker, Silex, Python, Node and WebSockets

    I’m learning Docker. In this post I want to share a little experiment that I have done. I know the code looks like over-engineering but it’s just an excuse to build something with docker and containers. Let me explain it a little bit.

    The idea is build a Time clock in the browser. Something like this:

    Clock

    Yes I know. We can do it only with js, css and html but we want to hack a little bit more. The idea is to create:

    • A Silex/PHP frontend
    • A WebSocket server with socket.io/node
    • A Python script to obtain the current time

    WebSocket server will open 2 ports: One port to serve webSockets (socket.io) and another one as a http server (express). Python script will get the current time and it’ll send it to the webSocket server. Finally one frontend(silex) will be listening to WebSocket’s event and it will render the current time.

    That’s the WebSocket server (with socket.io and express)

    var
        express = require('express'),
        expressApp = express(),
        server = require('http').Server(expressApp),
        io = require('socket.io')(server, {origins: 'localhost:*'})
        ;

    expressApp.get('/tic', function (req, res) {
        io.sockets.emit('time', req.query.time);
        res.json('OK');
    });

    expressApp.listen(6400, '0.0.0.0');

    server.listen(8080);


    That’s our Python script

    from time import gmtime, strftime, sleep
    import httplib2

    h = httplib2.Http()
    while True:
        (resp, content) = h.request("http://node:6400/tic?time=" + strftime("%H:%M:%S", gmtime()))
        sleep(1)


    And our Silex frontend

    use Silex\Application;
    use Silex\Provider\TwigServiceProvider;

    $app = new Application(['debug' => true]);
    $app->register(new TwigServiceProvider(), [
        'twig.path' => __DIR__ . '/../views',
    ]);

    $app->get("/", function (Application $app) {
        return $app['twig']->render('index.twig', []);
    });

    $app->run();


    using this twig template

    <!DOCTYPE html>
    <html lang="en">
    <head>
        <meta charset="utf-8">
        <meta http-equiv="X-UA-Compatible" content="IE=edge">
        <meta name="viewport" content="width=device-width, initial-scale=1">
        <title>Docker example</title>
        <link rel="stylesheet" href="https://maxcdn.bootstrapcdn.com/bootstrap/3.3.7/css/bootstrap.min.css" integrity="sha384-BVYiiSIFeK1dGmJRAkycuHAHRg32OmUcww7on3RYdg4Va+PmSTsz/K68vbdEjh4u" crossorigin="anonymous">
        <link href="css/app.css" rel="stylesheet">
        <script src="https://oss.maxcdn.com/html5shiv/3.7.3/html5shiv.min.js"></script>
        <script src="https://oss.maxcdn.com/respond/1.4.2/respond.min.js"></script>
    </head>
    <body>
    <div class="site-wrapper">
        <div class="site-wrapper-inner">
            <div class="cover-container">
                <div class="inner cover">
                    <h1 class="cover-heading">
                        <div id="display">
                            display
                        </div>
                    </h1>
                </div>
            </div>
        </div>
    </div>
    <script src="//localhost:8080/socket.io/socket.io.js"></script>
    <script src="https://ajax.googleapis.com/ajax/libs/jquery/1.12.4/jquery.min.js"></script>
    <script>
    var socket = io.connect('//localhost:8080');

    $(function () {
        socket.on('time', function (data) {
            $('#display').html(data);
        });
    });
    </script>
    </body>
    </html>


    The idea is to use one Docker container for each process. I like to have all the code in one place so all containers will share the same volume with source code.

    First the node container (WebSocket server)

    FROM node:argon

    RUN mkdir -p /mnt/src
    WORKDIR /mnt/src/node

    EXPOSE 8080 6400


    Now the python container

    FROM python:2

    RUN pip install httplib2

    RUN mkdir -p /mnt/src
    WORKDIR /mnt/src/python


    And finally Frontend contailer (apache2 with Ubuntu 16.04)

    FROM ubuntu:16.04

    RUN locale-gen es_ES.UTF-8
    RUN update-locale LANG=es_ES.UTF-8
    ENV DEBIAN_FRONTEND=noninteractive

    RUN apt-get update -y
    RUN apt-get install --no-install-recommends -y apache2 php libapache2-mod-php
    RUN apt-get clean -y

    COPY ./apache2/sites-available/000-default.conf /etc/apache2/sites-available/000-default.conf

    RUN mkdir -p /mnt/src

    RUN a2enmod rewrite
    RUN a2enmod proxy
    RUN a2enmod mpm_prefork

    RUN chown -R www-data:www-data /mnt/src
    ENV APACHE_RUN_USER www-data
    ENV APACHE_RUN_GROUP www-data
    ENV APACHE_LOG_DIR /var/log/apache2
    ENV APACHE_LOCK_DIR /var/lock/apache2
    ENV APACHE_PID_FILE /var/run/apache2/apache2.pid
    ENV APACHE_SERVERADMIN admin@localhost
    ENV APACHE_SERVERNAME localhost

    EXPOSE 80


    Now we’ve got the three containers but we want to use all together. We’ll use a docker-compose.yml file. The web container will expose port 80 and node container 8080. Node container also opens 6400 but this port is an internal port. We don’t need to access to this port outside. Only Python container needs to access to this port. Because of that 6400 is not mapped to any port in docker-compose

    version: '2'

    services:
      web:
        image: gonzalo123/example_web
        container_name: example_web
        ports:
         - "80:80"
        restart: always
        depends_on:
          - node
        build:
          context: ./images/php
          dockerfile: Dockerfile
        entrypoint:
          - /usr/sbin/apache2
          - -D
          - FOREGROUND
        volumes:
         - ./src:/mnt/src

      node:
        image: gonzalo123/example_node
        container_name: example_node
        ports:
         - "8080:8080"
        restart: always
        build:
          context: ./images/node
          dockerfile: Dockerfile
        entrypoint:
          - npm
          - start
        volumes:
         - ./src:/mnt/src

      python:
          image: gonzalo123/example_python
          container_name: example_python
          restart: always
          depends_on:
            - node
          build:
            context: ./images/python
            dockerfile: Dockerfile
          entrypoint:
            - python
            - tic.py
          volumes:
           - ./src:/mnt/src


    And that’s all. We only need to start our containers

    docker-compose up --build -d


    and open our browser at: http://localhost to see our Time clock

    Full source code available within my github account
